Specifications
1.Body manufactured in 0.8mm,1.0mm& 1.2mm sheet steel for choose. 2.Door in 1.0mm or 1. 2 sheet steel up to 800H. 3.Protection degree:IP40,IP55,IP65 different standards for the markets requirements. Steel enclosure are suitable for corrosive environments installations where hygienic essential in chemical and food industries, etc. Monobloc watertight steel enclosures. Types ALS304 or ALS316 also available on request. 4.Mounting plate in 1.0 to 2.5mm sheet steel zinc coated. 5.Hinge in zinc alloy on the body and stainless steel on the door. or some other requirements. 6.Protection Degree: IP 40,50,55,65 7.Supply Includs: Boxes are complete with: 7.1Mounting plate. 7.2Package with hardware for earth connection and screws to mounting plate. 7.3Locking system body in zinc alloy. 7.4Supply include: enclosure body,door with locking system and galvanised mounting plate,sealing gasket and fixing accessories wall mount brackets 4pcs/set to be offered separately Note:Due to the light, there may be some color difference between the product color and the picture color,so colour should be confirm from the real sample
Technical Data
| Metal distribution box | |||
| Sizes | Thickness | Weight(Kgs) | |
| Body | Door | ||
| 300x250x200 | 0.8 | 1 | 3.1 |
| 300x300x200 | 0.8 | 1 | 3.6 |
| 500x400x200 | 0.8 | 1 | 6.8 |
| 600x400x200 | 0.8 | 1 | 8 |
| 700x500x200 | 0.8 | 1 | 10.8 |
| 800x600x200 | 0.8 | 1 | 14.2 |
